model

STSQ5-1

main hook winch

5T winch

Chassis model

Dongfeng Dolica

Reducer model

Planetary reducer

Maximum weight

5000KG

Slewing ring

840#

jib

5 meters*5 knots

engine pump

40#

Maximum Lifting Height

20m

center rotation

electric rotation

Outrigger span (horizontal * vertical)

5.9*3.5m

Large frame size

220*70mm

Dimensions

5.98*1.9*2.6m

Boom size

340*305

Lifting speed auxiliary/main hook

36(95)-76m/min

rear shift top

have

Swing speed

0-3 rpm

direction form

help

engine model:

diesel engine

brake form

oil brake

engine power

85KW/115

gearbox

Wanliyang 5th gear

tire model

650R15

wheelbase

2750mm

Driving speed

95 Km/h

Actual/Advertised Weight

4495KG

air conditioner

front air conditioner

Optional:Electric air conditioner
