model

STSQ10B

wheelbase

2.86m

Chassis model

Kaima 2860

main hook winch

Inclined axis winch

Maximum weight

10000 Kg

Auxiliary hook winch (spare equipment)

Inclined axis winch

Maximum Lifting Height

26m/30m

Reducer model

Planetary reducer

U-shaped boom

6 meters 5 knots  (single board arm)

5.5 meters 7 knots (outer rope)

Slewing ring

QWA.1000.32

Outrigger span (horizontal * vertical)

6.33x4.26m

(Knuckles)

engine (single pump)

50 Pump

large telescopic

1.3m

motor (single pump)

40 Pump

Dimensions

7.585*2.2*3.03m

center rotation

big three holes

Motor Power

11kw 4 poles

Large frame size

400*200*8mm

Lifting Speed Brush/Main Hook

80/min

Boom size

461*326mm

Swing speed

0-3rpm

rear shift leg

standard

Counterweight retractable

0.5m

direction form

help

Radius of gyration

1.5m

brake form

air brake

engine model

4DB1

gearbox

10H46

engine power

95KW

Axle model

1070

tire model

8.25-16 Steel tire

Actual-Announced Weight

11200kg

Driving speed

80km/h

Other configurations:negative angle,electronic throttle
