model

STSQ6D

main hook winch

8T inclined axis

Maximum weight

6000kg

Reducer model

planet

Maximum Lifting Height

25m

Slewing ring

900#

jib

3.5meters*knots

engine pump

50 pumps

Outrigger span (horizontal * vertical)

4.8*5.05m

5.87*5.08m

motor pump

50 pumps

large telescopic

1.3m

center rotation

center rotation

Telescopic weight box

0.5m

Large frame size (telescopic large frame)

300*150*6mm

Dimensions (length, width and height)

5.25*1.70*2.25m

5.68*2*2.74m

Boom size

480*290mm

Motor Power

11KW

rear shift top

Standard

Lifting speed

85(m/min)

Front and rear outriggers

Standard

Swing speed

0-3(r/min)

direction form

direction assistance

engine model

490 engine

brake form

air brake

engine power

37KW

gearbox

140

tire model

700-16R(Steel tire)

Axle model

 oil brake bridge

Driving speed

55kw/h

Self-respect

7.6T/8.2T

wheelbase

2.04m

Ground clearance:

240/260(mm)
