performance

Load mode

500kg

1000kg

3000kg

Working range

7.3m

5.2m

1.5m

specifications

3T

Maximum homework radius

12.5M

Maximum above ground lift

13.5M

Hook lifting speed

12m/min

Specification of steel wire rope

Φ8mm*50m

Crane arm form

5-section boom, multi rib structure

Telescopic arm length

4m~12.5m

Crane arm angle/time

0~82°(Arm lifting: 24 seconds, arm climbing: 12 seconds)

Rotation angle/speed

0~360°(Continuous)/60 seconds

Leg movement form

Manual rotation+hydraulic automatic support (two legs)

Gradeability

15°

size

vehicle size

4000mm*1200mm*2070mm

tire

Front wheel 28X9-15, rear wheel 6.50-10

Maximum extension range of supporting legs

Left and right (4920mm) front and back (3200mm)

engine

model

Changchai 390

power

25kw

start mode

Electric start

start performance

-10 degrees Celsius to 40 degrees Celsius

Fuel/Volume

Diesel/11L

Battery capacity

12v 80AH

emission standard

Country 2

Whole machine weight

3400kg
