Maximum homework radius

14.5m

Maximum ground lift

16.2m

Winching device

Hook lifting speed

12m/min(4rope)

Specification of steel wire rope

Φ11mm*80m

Expansion device

Crane arm form

5-section lifting arm, U-shaped structure

Telescopic arm length

4.7m-16.5m

Long term suspension arm

12.3m/54 second

Undulating device

Boom angle/time

0-78°/13 second

Gyratory device

Rotation angle/speed

0-360°(continuity)/38 second

Outrigger

Leg movement form

Manual rotation+oil pressure automatic support (two legs)

Maximum extension amplitude

about(6700mm)around(4700mm)

Walking device

Walking mode

Hydraulic motor drive

Walking speed

0-2.5km/h

Climbing ability

20°(36%)

Electrical machinery

voltage

AC380V

engine

Production party

in-cloud

Form/displacement

490

Starting method

Electric start

Startup performance

-5°C-40°C

Fuel/Volume

diesel oil/60L

Battery capacity

12v 80AH

emission standard

National level two

operating system

Operation type (boom/leg)

Manual operation, manual walking

Operational characteristics

Manual operation

Standard configuration

Diesel engine and electric motor (dual power)

vehicle size

5050mm*1400mm*2200mm

Total weight

6000kgs
