Bodywork configuration

Car configuration

working height

26 meters

chassis

JMC Shunda

Maximum operating range

14.6 meters

engine

Jiangling 116 horsepower

Working platform rated load

200KG

gearbox

Wanliyang 5th gear

Outrigger span (front V rear H)

4295/4286mm(Lateral front/rear)

tire

700-16

3995/3845mm(longitudinal front/rear)

wheelbase

3360mm

Rotary device

360°infinite spin gondola

360°turn around

Axle load

1895/2600KG

Boom structure

Five-section arm Synchronous scaling

vehicle size

5995*2050*3100mm

Operation method

turntable, remote control

total mass

4495KG

Basket size

1350*700*1100mm

curb weight

4365KG

number of passengers

2 people
